120BBL Beer Unitanks

120BBL Stainless Steel Conical Beer Fermenters

120BBL Beer Unitanks is also called CCT (Cylindrical Conical Tank), FV (Fermentation Vessel), primary fermentor or unitank as they are used both for fermenting and lagering. Fermenting is the process during which the yeast transforms the wort into beer. Lagerings takes place after fermenting and is the time given to the beer to stabilize and age after fermenting.A 120-barrel (bbl) stainless steel beer fermenter is a large vessel used in commercial breweries for fermenting beer. It’s a significant piece of equipment typically found in breweries with substantial production capacity.

Advantage：

Certified stainless-steel material. Sanitary construction with 100% TIG welded joints and seams with sanitary interior polish. All stainless steel beer fermenter and jackets inspected and pressure tested to 2 times operating pressure. All stainless steel beer fermenter insulated with high efficiency polyurethane foam. We can custom fabricate any stainless steel beer fermenter to meet your brewery’s space and height restrictions. Tank design pressure is 30 PSI。

Standard product features:

• Function：Wort Fermentation or maturation
• Stainless steel beer fermenter:w/ 25% head space.
• Design pressure 30psi or 2
• Interior shell: SUS304, thickness 3mm.
• Exterior shell: SUS304, thickness 2mm.
• Interior and exterior finish bright polish to 2B, hygienic surface.
• 60° conical cone bottom.
• Racking port and discharge port with butterfly valve and fittings.
• Side manway door, shadowless.
• Dimple glycol cooling jackets with glycol inlets and outlets.
• Polyurethane foam insulation, thickness 80mm/>3” on side and bottom.
• Fully welded exterior shell.
• 4 legs with levelling foot pads.
• CIP arm and spray ball.
• Rotating racking arm.
• Vacuum relief at 2bar.
• Pressure relief valve at 30psi as standard.
• Sanitary pressure gauge.
• Perlick style sample valve.
• Stainless steel beer fermenter comeswith fittings, valves, and all parts.
• Lifting Lugs.
• P100 temperature sensor.
• Carbonation stone.
• Dry hopping portwith solid end cap
• 24V DC liquid solenoid valve.

OPTIONS:

• Additional blow off pipework.
• Larger drain ports.
• Tangential inlets.
• Glycol pipework.
