4000L Beer Fermenting Vessel

4000L _Beer _Fermenters_Unitanks

A 4000-liter (L) beer fermenter or unitank is a substantial vessel used in breweries for fermenting and conditioning beer. These tanks are typically found in medium to large breweries where significant quantities of beer are produced. A 4000L fermenter or unitank has a total capacity of 4000 liters, which is approximately 1056 gallons. This large capacity allows breweries to ferment substantial volumes of beer in a single vessel, making it suitable for medium to large-scale production.

Advantage：

Certified stainless-steel material. Sanitary construction with 100% TIG welded joints and seams with sanitary interior polish. All beer fermenters and unitanks inspected and pressure tested to 2 times operating pressure. All tanks insulated with high efficiency polyurethane foam. We can custom fabricate any beer fermenter and unitank to meet your brewery’s space and height restrictions. Beer fermenter and unitank design pressure is 30 PSI。

Standard product features:

• Fermentation vessel w/ 25% head space.
• Design pressure 30psi or 2
• Interior shell: SUS304, thickness 3mm.
• Exterior shell: SUS304, thickness 2mm.
• Interior and exterior finish bright polish to 2B, hygienic surface.
• 60° conical cone bottom.
• Racking port and discharge port with butterfly valve and fittings.
• Side or Top man way door, shadowless.
• Dimple glycol cooling jackets with glycol inlets and outlets.
• Polyurethane foam insulation, thickness 80mm/>3” on side and bottom.
• Fully welded exterior shell.
• 4 legs with levelling foot pads.
• CIP arm and spray ball.
• Rotating racking arm.
• Vacuum relief at 2bar.
• Pressure relief valve at 30psi as standard.
• Sanitary pressure gauge.
• Perlick style sample valve.
• Beer fermenter and unitank comeswith fittings, valves, and all parts.
• Lifting Lugs.
• Dry hopping port
• Carbonation stone.
• P100 temperature sensor.
• 24V DC liquid solenoid valve.

OPTIONS:

• Additional blow off pipework.
• Larger drain ports.
• Tangential inlets.
• Glycol pipework.
