Main Technical Parameters
Equipment Outer Dimensions | 1000*850*1550mm |
Net Weight | 130KG |
Power | 60W |
Production Capacity | 60-80kegs/H |
Filling Method | Keg Topside up |
Applicable Kegs | Keg with Diameter 250-500mm, Height 360-600mm |
Power Supply Voltage | AC 220V 50HZ(customized) |
Main function and feature
1.All procedures are thoroughly controlled by SIEMENS programmable controller. All parameters (time values) can be adjusted without stopping the machine.
2.Two filling stations with separate control systems.
3.Pressure maintaining system performance is stable and reliable, to make sure the lowest beer loss compared to other similar products.
4.Could fill the kegs with different volume directly, and do not need to adjust any parameter.
Working process:
Fix the keg —Start — Co ₂ pressurization -Filling– stop– Take the keg
