Four Heads Beer Keg Washer is an automatic, 4heads system designed to clean and sanitize beer kegs efficiently,this equipment is particularly useful for breweries as it can handle several kegs simultaneously, reducing the time and labor required for keg cleaning.
Four Heads Beer Keg Washer is an automatic, 4heads system designed to clean and sanitize beer kegs efficiently.
This equipment is particularly useful for breweries as it can handle several kegs simultaneously, reducing the time and labor required for keg cleaning.
| 1 | Size:W*L*H | 3.20*1.70*2.10M | |||
| 2 | Weight | 450KG | |||
| 3 | with slide or not | No | Yes | ||
| 4 | Packing Size （L*W*H) | 3.41*1.90*2.35M | |||
| 5 | Gross Weight | 700KG | |||
| 6 | Capacity | Washing part: | 60-120pcs/h | ||
| 7 | Power | According to user local power | |||
| 8 | Power port | 3P+N+G | |||
| 9 | Heater way | Steam Coiler | Electrical Heater | ||
| 10 | Power consumption | 5.0KW | 17.5KW | ||
| 11 | Main Material | SUS304 | |||
| 12 | Water tank material and volume | SUS304 Single tank / Volume=160L （3pcs） | |||
| 13 | Motor type and brand | SUS304 Pump Head | |||
| 14 | Temperature prode | NTC | |||
| 15 | Temperature control mode | STC-200 | |||
| 16 | Time setting way | Siemens PLC 200 Smart | |||
| 17 | Connect type | water inlet and drain outlet | 1.5″ Tri-clamp | Steam inlet | DIN male fitting |
| 18 | Spear type | A | S | D | G |
| 19 | Keg type | EURO DIN AMERICAN 20L-60L keg | |||
| 20 | Washing part inlet with pressure detection or not | Yes | No | ||
| 21 | Washing part outlet with the residual liquid detection or not) | Yes | No | ||
| 22 | Washing working procedure | Lock down→ air purge/drain off → rinse water washing→ air purge/drain off → caustic washing → air purge/to caustic tank → hot water 1 washing → air purge/drain off →hot water 2 washing →steam purge/drain off to rinse water tank →steam sterilized → steam keep pressure sterilized→CO2 purge/drain off→CO2 fill→cylinder returnLock down→ air purge/drain off → hot water 1 washing→ air purge/drain off → caustic washing → air purge/to caustic tank → hot water 2 washing → air purge/drain off →sanitizer sterilize → CO2 purge/to sanitizer tank→hot water 3 washing →CO2 purge/drain off→CO2 fill | |||
| 23 | Package | Composite board boxes | |||
