Brewery fermentation tanks with a capacity of 6000 liters are large vessels used in the brewing industry for the fermentation stage of beer production. Here’s an overview of what they are and their key features:

1.Description

• Capacity: 6000 liters (approximately 1585 gallons)
• Material: Typically made from stainless steel to ensure durability and ease of cleaning.
• Shape: Cylindroconical (cylinder with a conical bottom) design is common for optimal yeast sedimentation and easy yeast harvesting.
• Insulation:with PUinsulated to maintain consistent fermentation temperatures.
• Cooling Jackets: Many tanks include cooling jackets to control temperature during fermentation.
• Pressure Rated: brewery fermentationtanks are designed to handle pressure, which is important for certain styles of beer and for carbonation processes.

2.Standard product features:

• Fermentation vessel w/ 25% head space.
• Design pressure 30psi or 2
• Interior shell: SUS304, thickness 3mm.
• Exterior shell: SUS304, thickness 2mm.
• Interior and exterior finish bright polish to 2B, hygienic surface.
• 60° conical cone bottom.
• Racking port and discharge port with butterfly valve and fittings.
• Side or Top man way door, shadowless.
• Dimple glycol cooling jackets with glycol inlets and outlets.
• Polyurethane foam insulation, thickness 80mm/>3” on side and bottom.
• Fully welded exterior shell.
• 4 legs with levelling foot pads.
• CIP arm and spray ball.
• Rotating racking arm.
• Vacuum relief at 2bar.
• Pressure relief valve at 30psior 2bar as standard.
• Sanitary pressure gauge.
• 5’’sample valve.
• Brewery fermentation tanks comeswith fittings, valves, and all parts.
• Lifting Lugs.
• Thermowell.
• Dry hopping port
• Carbonation stone.
• P100 temperature sensor.
• 24V DC liquid solenoid valve.

OPTIONS:

• Additional blow off pipework.
• Larger drain ports.
• Tangential inlets.
• Glycol pipework.

3.Use in Brewing Process

1. Wort Addition: After boiling, the wort (unfermented beer) is transferred into the fermentation tank.
2. Yeast Pitching: Yeast is added to the wort to start the fermentation process.
3. Fermentation: Yeast converts sugars in the wort into alcohol and carbon dioxide. The temperature is carefully controlled.
4. Conditioning: After primary fermentation, the beer may remain in the tank for conditioning, allowing flavors to mature.
5. Carbonation: If the tank is pressure-rated, carbonation can occur in the same vessel.

4.Benefits

• Scalability: Large capacity supports commercial-scale production.
• Efficiency: Streamlined design for easy yeast removal and cleaning.
• Consistency: Precise control of fermentation conditions for consistent quality.

6000L brewery fermentation tanks are typically used by medium to large breweries.If you have any specific questions or need more detailed information for 6000L brewery fermentation tanks, feel free to ask!
